Name: EVO II Pro V2 Rugged Bundle - Megarobotic
Price: 37300000 IDR
Availability: InStock

First 6K folding drone
Sony’s supersensitive 1″ CMOS sensor capable of 6k Ultra HD Videos
Adjustable aperture range of f2.8 to f11 and a maximum ISO of 12,800
10-bit A-log post-production flexibility
360° obstacle avoidance with 19 groups of sensors
Industry-leading 40 minutes flight time
Transmission range of 9KM

OVERVIEW

Autel EVO II Pro V2 Rugged Bundle

Leader In Picture Quality And Flight Intelligence, First 6K Folding Drone

The EVO II Pro’s advanced camera settings include an adjustable aperture range of f2.8 to f11 and a maximum ISO of 12,800 enabling the photographer to produce images of exceptional precision and sharpness.

Using Sony’s supersensitive CMOS sensor, the EVO II Pro provides impressive low-light photography video resolutions up to 6K, greater dynamic range, and stronger noise reduction.

10-bit A-log Post-Production Flexibility

10-bit camera allows the EVO II Pro to record up to 1 billion colors. The EVO II Pro retains rich detail in shadows and highlights, allowing greater flexibility in post-production.

Only Autel Offers Hyperlapse In 6K

With Hyperlapse mode, no post processing is required. The 6K images can be taken straight out of the drone and shared immediately. JPEG and RAW files are recorded simultaneously. Create perfect flight paths and produce accurate, repeatable hyperlapse videos with just one click.

SkyPortrait: Your Personal Paparazzi

With the touch of a button, the Nano will rise into the air and snap a photo of you and your friends, automatically adjusting the lens so no one gets left out.

Dynamic Track 2.1: Master Subject Tracking

Recruit your Nano to automatically follow any person, so you can focus on your activities while your Nano handles the cinematic side.

360° Obstacle Avoidance

Equipped with 19 groups of sensors — including 12 visual sensors, the main camera, ultrasound, and dual IMUs — the EVO II Pro can easily build three-dimensional maps and plan paths through complex terrain in real time.

Dynamic Track 2.0

The EVO II Pro can model the location and speed of targets simultaneously, predict their trajectory accurately, and track them continuously while identifying up to 64 objects at the same time.

SPECS

Aircraft

Takeoff weight	1191 g
Max takeoff weight	2000 g
Wheelbase	397 mm
Size(LWH)	230x130x108 mm (folded) 457x558x108 mm (unfolded)
Maximum service ceiling altitude	7000 m
Max ascent speed	8 m/s (Ludicrous)
Max descent speed	4 m/s (Ludicrous)
Max horizontal flight speed	20m/s (Ludicrous)
Max flight distance (no wind)	25 km
Max tilt angle	33° (Ludicrous)
Max angular velocity	120°/s
Max flight time (no wind)	40 min
Max hovering time (no wind)	35 min
Operating temperature range	-10℃ ~ 40℃
Maximum resistance to wind	12 m/s (Take-off and landing)
Operating frequency	902-928MHz (FCC Only) 2.400-2.4835GHz 5.725-5.850GHz (non-Japan) 5.650-5.755GHz (Japan Only)
Transmission power	900M FCC/ ISED：≤31dBm 2.4G FCC/ ISED：≤32dBm SRRC/CE/MIC/RCM：≤20dBm 5.8G (non-Japan) ; 5.7G (Japan) FCC/ISED/SRRC/MIC：≤33dBm CE/ RCM：≤14dBm
Hovering accuracy	Vertical: ±0.1 m (when the visual positioning is working normally); ±0.5 m (when GPS works normally) Horizontal: ±0.3 m (when the visual positioning is working normally); ±1.5 m (when GPS works normally)
GNSS	GPS/Beidou/Glonass/Gallieo
Internal storage	8GB
SD storage	max. support 256GB (UHS-3 or Class 10)

Gimbal

Gimbal	3-axis stabilization
Mechanical range	Tilt: -135° to +45°; Pan: -100° to +100°
Controllable rotation range	Tilt: -90° to +30°; Pan: -90° to +90°
Max control speed (Tilt)	300°/s
Angular Vibration Range	±0.005°

Remote controller and image transmission

Operating frequency	902-928MHz (FCC Only) 2.400-2.4835GHz 5.725-5.850GHz (non-Japan) 5.650-5.755GHz (Japan Only)
Transmission power	FCC：≤33dBm CE：≤20dBm@2.4G，≤14dBm@5.8G SRRC：≤20dBm@2.4G，≤33dBm@5.8G/5.7G
Max Transmission Distance (unobstructed, free of interference)	FCC：15km CE：8km
Display screen	2340×1080 60fps
Battery	1900mAh
Operating time	~2 hours (Max. Brightness) ~3 hours (50% Brightness)
Charging time	90 minutes
Internal Storage	ROM 128GB + expandable storage via micro-SD card

Sensing system

Sensing system type	Omnidirectional sensing system
Forward	Accurate measurement range: 0.5-18 m Effective sensing speed:<12m/s Viewing angle: Horizontal: 60°, Vertical: 80°
Backward	Accurate measurement range: 0.5-16 m Effective sensing speed:<12m/s Viewing angle: Horizontal: 60°, Vertical: 80°
Upward	Accurate measurement range: 0.5-10 m Effective sensing speed:<5m/s Viewing angle: Horizontal: 65°, Vertical: 50°
Downward	Accurate measurement range: 0.5-10 m Effective sensing speed:<5m/s Viewing angle: horizontal: 100°, vertical: 80°
Left and right	Accurate measurement range: 0.5-10 m Effective sensing speed:<5m/s Viewing angle: horizontal: 65°, vertical: 50°
Operating Environment	Forward, Backward and Sides: Surface with clear pattern and adequate lighting (lux > 15) Upward: Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.) Downward: Surface with clear pattern and adequate lighting (lux > 15) Detects diffuse reflective surfaces (>20%) (walls, trees, people, etc.)

Camera

Sensor	1 inch CMOS; 20M pixels
Lens	FOV: 82° Equivalent focal length: 29 mm Aperture: f/2.8 – f/11 Focus range: 0.5 m to infinity
ISO range	Video: 100-44000 Photo: 100-6400
Shutter speed	Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates
Zoom	1-16x (up to 3x lossless zoom)
Photo mode	Single shot/Burst shooting/AEB/Time Lapse/HDR
Maximum photo size	54723648 (3:2) 54723076 (16:9) 3840*2160 (16:9)
Image Format	JPG (default) / DNG / JPG+DNG
Photo mode	5472x3076P30/P25/P24 3840x2160P60/P50/P48/P30/P25/P24 2720x1528P60/P50/P48/P30/P25/P24 1920x1080P60/P50/P48/P30/P25/P24
Video format	MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)
Max bitrate	120Mbps
Supported file system	FAT32/exFAT

Battery

Capacity	7100 mAh
Voltage	11.55 V
Battery type	LiPo 3S
Energy	82 Wh
Weight	365 g
Charging temperature range	5℃ to 45℃
Storage temperature and humidity	-10~30℃，65±20%RH
Recommended storage temperature	22-28℃
Max charging power	93W
Charging time	90 minutes

Charger

Input 100-240 V, 50/60 Hz, 1.5A

Output 13.2 V ⎓ 5 A
5V⎓3A 9V⎓2A 12V⎓1.5A

Voltage 13.2±0.1V

Rated power 66W
Multi-Charger

Voltage 13.2 V

Charging temperature range 5℃ to 45℃

IN THE BOX

Autel EVO II Pro V3 Rugged Bundle Package List

autel robotics evo ii pro rugged package pc

Autel EVO II Hard Case

autel evo ii hard case

DOWNLOAD

Name	Download
Autel EVO II Pro V3 Brochure	Download_File
Autel EVO II Pro V3 Public Safety Brochure	Download_File
Specs For Autel EVO II Pro V3	Download_File
Autel Smart Controller SE Brochure	Download_File
Specs For Autel Smart Controller SE	Download_File
Autel Live Deck 2 Brochure	Download_File
Specs For Autel Live Deck 2	Download_File
