EVO II Pro Enterprise V3

• Remote ID Updated
• 7.9″ Smart Controller V3
• Include Speaker/Spotlight/Stobe
• 1″ CMOS Sensor Gimbal Camera
• 12-bit DNG A-Log
• 20MP Photo& 6K/30fps Video
• 360° Obstacle Avoidance
• Dynamic Track 2.1
• ADS-B Singal Receiver
• 15km Transmission Range
• 42 Minutes Flight Time
• 9 Miles Video Transmission Range

OVERVIEW

EVO II Pro Enterprise V3

Autel EVO II Pro RTK V3 is an advanced drone model that offers an impressive range of features designed for surveying and mapping applications. This drone is equipped with advanced RTK technology that allows it to achieve highly accurate positioning with an accuracy of up to 1cm+1ppm (1.5cm+1ppm). This makes it ideal for use in a wide range of industries, including construction, agriculture, and mining.

Overall, the Autel EVO II Pro RTK V3 is an outstanding drone that delivers exceptional performance and versatility for surveying and mapping applications. Whether you are working in construction, agriculture, or any other industry that requires highly accurate data and detailed maps, the Autel EVO II Pro RTK V3 is the ideal solution for your needs.



Work Like Never Before

Optimize your workflow with our toughest EVO II Pro Enterprise V3 yet, bulked up with new accessories and camera features to meet the demands of professionals in every industry from firefighting to construction. With a foldable design that can be deployed in seconds and easy-to-use controls that can be operated with a single hand, the EVO II Dual 640T provides a surefire way to increase efficiency without increasing stress.

Autel SkyLink 2.0 Video Transmission

SkyLink 2.0 is built into the EVO II Pro Enterprise V3 chipset, expanding the possibilities for your most critical workflows.



Mission Planner

Rectangular and Polygon mission planners – Those are going to be great for anybody that’s dealing with photogrammetry. So anybody that needs to be able to capture a lot of images in a rectangular mission or polygon mission, you’re going to be able to do that in an autonomous fashion. Then you’re going to be able to take EVO II Pro Enterprise V3’s images and upload them to your 3D mapping

Autel Smart Controller V3

Smart Controller V3’s 7.9-inch, 2000 nit high-brightness screen is clearly visible even under direct sunlight. SkyLink 2.0 Transmission technology guarantees long-distance operations from up to 9 miles away and enhances anti-interference abilities with triple-band frequency hopping. The customized Android system allows for additional flexibility with 3rd party apps and an IP43 rating ensures all weather performance.

Broadcast with Live Deck 2

Transmit real-time HD video to a wide-variety of devices, allowing cross-departmental teams enhanced situational awareness and communication which can lead to quicker and better decision making.(Support all EVO II V3 drones.)

EVO II – AI Enhanced Dynamic Track

EVO II Pro Enterprise V3 can model location and speed of targets simultaneously, predict their trajectory accurately, avoiding obstacles during flight, and track them continuously while identifying up to 64 objects at the same time. The function can track the subject in three modes: behind, side-by-side, or fixed position.

360° Obstacle Avoidance

EVO II Pro Enterprise V3 Drone’s front, rear, left, right, top, and bottom binocular vision sensing systems use image data to calculate the distance between the aircraft and potential obstacles. Begin detecting potential hazards at up to 30m away and let EVO II accurately control the speed of the drone to avoid a collision.

Multiple Intelligent Flight Modes

Autel EVO II Drone supports multiple smart Flight Modes includes Dynamic Track, Parallel Track, Tripod Track, Viewpoint, Orbit, Gesture control, VR Flight, Waypoint and more.

Failsafe & Automatically Return Home

EVO 2 Enterprise V3 will return home automatically when Low Aircraft Battery Level and Communication Lost. Additionally, EVO 2’s bottom binocular vision camera to create a density depth map. Then, it calculates the depth map’s flatness and angles to ensure an accurate and safe landing.

42 Minutes & 9 Miles HD Transmission

Autel EVO 2 Enterprise V3 comes standard with a 7100mAh rechargeable battery. Providing up to 42 mins of flight time in forward motion to up to 15km (9 miles) away and 35min at a hover. And top speed up to 45MPH, additionally There is no geofencing or cellular service restrictions on any of EVO II.

Enterprise Bundle Accessories

•

  • Support Live Deck 2
  • Moonlight Algorithm 2.0
  • Autel Skylink 2.0
  • Smart Controller V3
  • 15KM Tansmission
  • 2.4GHz/5.8GHz/900MHz
•



  • /
  • /
  • Autel SkyLink
  • Smart Controller V2
  • 9KM Transmission
  • 2.4GHz/5.8GHz

Autel Explorer For Mapping

SPECS

Autel EVO II Pro Enterprise V3 6K Drone Specification

Aircraft
Takeoff Weight (Without Accessories)	EVO II Pro Enterprise V3 Enterprise：2.45lbs (1110g) EVO II Dual 640T Enterprise：2.51lbs (1136.5g)
Max Takeoff Weight	1999 g
Diagonal Length	16.8 inches (427 mm)
Size(L*W*H)	Folded: 9.6*5.1*4.4 inches; 245*130*111mm Unfolded: 19.9*24.4*4.4 inches; 506*620*111mm
Max Takeoff Altitude	4.3 miles (7000 m) MSL
Max Ascent Speed	18 mph (8 m/s) (Ludicrous)
Max Descent Speed	9 mph (4 m/s) (Ludicrous)
Max Level Flight Speed	45 mph (20 m/s) (Ludicrous)
Max angular velocity	120°/s
Max tilt angle	33° (Ludicrous)
Max Flight Time (no wind)	42 min（without accessories）
Max Hovering Time (no wind)	38 min(with strobe) 29 min(with spotlight) 34 min(with loudspeaker) 36 min(with RTK module)
Operating Temperature Range	14℉ to 104℉ (-10℃ to 40℃)
Max Wind Speed Resistance	27mph, 12 m/s (Take-off and landing)
Operating Frequency	2.400 GHz – 2.4835 GHz； 5.725GHz – 5.850 GHz
Hovering accuracy	When RTK is enabled and working normally: Vertical: ±0.1 m; Horizontal: ±0.1 m Vertical: ±0.1 m (when the visual positioning is working normally); ±0.5 m (when GNSS works normally) Horizontal: ±0.3 m (when the visual positioning is working normally); ±1.5 m (when GNSS works normally)
Internal storage	8GB
SD storage	max. support 256GB (UHS-3 or Class 10)
Gimbal
Gimbal	3-axis stabilization
Mechanical range	Tilt: -135° to +45°; Pan: -100° to +100°
Controllable rotation range	Tilt: -90° to +30°; Pan: -90° to +90°
Max Control Speed (Tilt)	300°/s
Angular Vibration Range	±0.005°
Camera
Sensor	1″ CMOS Effective Pixels: 20 MP
Lens	FOV: 82° 35 mm format equivalent focal Equivalent focal length: 29 mm Aperture: f/2.8 – f/11 Focus range: 0.5 m to infinity
ISO Range	Video: 100-44000 Photo: 100-6400
Shutter Speed	Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates
Zoom	1 ~ 16x (Max. 3x lossless zoom)
Photo mode	Single shot/Burst shooting/AEB/Time Lapse/HDR
Maximum photo size	5472*3648 (3:2) 5472*3076 (16:9) 3840*2160 (16:9)
Image Format	JPG (default) / 12bits DNG / JPG+12bits DNG
Photo mode	5472x3076P30/P25/P24 3840x2160P60/P50/P48/P30/P25/P24 2720x1528P60/P50/P48/P30/P25/P24 1920x1080P60/P50/P48/P30/P25/P24
Video format	MP4 / MOV (MPEG-4 AVC/H.264, HEVC/H.265)
Max bitrate	120Mbps
Supported file system	FAT32/exFAT
Remote Controller
*Operating Frequency	902-928MHz (FCC Only) 2.400-2.4835GHz 5.725-5.850GHz (non-Japan) 5.650-5.755GHz (Japan Only)
Max Transmission Distance(unobstructed, free of interference)	FCC: 15km CE: 7km
Transmitter Power (EIRP)	902-928 MHz FCC:≤30dBm 2.400-2.4835 GHz FCC:≤30dBm CE：≤20dBm 5.725-5.850 GHz CE：≤14dBm
Internal Storage	128GB
Display screen	2048×1536 60fps
Battery	5800mAh
Operating time	~3 hours (Max. Brightness) ~4.5 hours (50% Brightness)
Charging time	90 minutes
Internal Storage	ROM 128GB
Accessories
Strobe	Dimensions: 39*72*34 mm Weight: 19.5g Connections: Floating Connectors Power：Avg. 1.6W Controllable Range：5000m Light intensity：Min 50cd；Max 486cd；Avg. 290cd
Loudspeaker	Dimensions:46*80*77 mm Weight: 98.5g Connections: Floating Connectors Power：Max 18W Decibel：120dB @ 1m；88dB @ 60m；70dB @ 110m； Max Bitrate：36kbps Adjustable Angle Range：0°~45°
Spotlight	Dimensions: 48.5*72*63 mm Weight: 77g Connections: Floating Connectors Power：Max 35W Controllable Range：30m Adjustable Angle Range：0°~90° Illuminance：FOV14°, Max：11lux @ 30m Straight
RTK Module(sold separately)	Dimensions：55.5*72.5*57 mm Weight：59.5 g Connections：Floating Connectors Power：~ 3W RTK Positioning Precision： 1.5 cm + 1 ppm（(Vertical） 1 cm + 1 ppm（Horizontal）
Battery
Capacity	7100 mAh
Voltage	11.55 V
Battery Type	LiPo 3S
Energy	82Wh
Net Weight	365g
Charging Temperature	5~45℃
Storage Temperature & Humidity	-10~30℃，65±20%RH
Recommended Storage Temperature	22~28℃
Max Charging Power	93 W
Charging Time	90 mins
Charger
Input	100-240 V, 50/60 Hz, 1.5A
Output	13.2 V ⎓ 5 A 5V⎓3A 9V⎓2A 12V⎓1.5A
Voltage	13.2 ± 0.1 V
Rated Power	66 W
Multi-Charger
Voltage	13.2 V
Charging temperature range	5℃ to 45℃

IN THE BOX

Autel EVO II Pro RTK V3 Package List
